IPLEX NX
发布时间: 2019-05-21 00:00
高端的工业视频内窥镜系统地组合了多种先进功能，使用更具便捷性与耐久性。从高画质检测到外来异物的抓取，多样化的性能带给用户前所未有的体验。
SCOPE UNIT
|
|
IV9435N | IV9450N | IV9635N | IV9650N | IV9675N | |
| Insertion tube | Insertion tube |
4.0 mm (0.157 in.) |
4.0 mm (0.157 in.) |
6.0 mm (0.236 in.) |
6.0 mm (0.236 in.) |
6.0 mm (0.236 in.) |
| Scope length |
3.5 m (11.5 ft.) |
5.0 m (16.4 ft.) |
3.5 m (11.5 ft.) |
5.0 m (16.4 ft.) |
7.5 m (24.6 ft.) |
|
| Exterior | High-durability tungsten braid | |||||
| Tube flexibility | Uniform stiffness | Tapered Flex insertion tube with flexibility gradually increasing toward the distal end | ||||
| Optical system | Field of view |
Selectable by optical tip adaptor Adaptor for Stereo measurement attachable |
||||
| Direction of view | ||||||
| Illumination | High-intensity laser diode | |||||
| Articulation section |
Articulation angle Up/Down/Right/Left |
130° | 180° | 150° | ||
| Articulation operation | TrueFeel scope tip articulation with electronic power-assist | |||||
BASE UNIT
|
|
IV9435N | IV9450N | IV9635N | IV9650N | IV9675N | |
| Dimensions (W x H x D) |
320 mm x 310 mm x 180 mm (12.6 in. x 12.2 in. x 7.1 in.) |
|||||
| Weight |
3.9 kg (8.6 lbs.) |
|||||
|
Approx. system weight (with battery and SDHC card) |
7.1 kg (15.7 lbs.) |
7.2 kg (15.9 lbs.) |
7.3 kg (16.1 lbs.) |
7.4 kg (16.3 lbs.) |
7.6 kg (16.8 lbs.) |
|
| LCD monitor | 8.4-inch daylight-view touch screen LCD, clear type | |||||
| Input/Output terminal | Input terminal | S-Video | ||||
| Output terminal | VGA | |||||
| USB connector | Type A connector, Version 2.0 standards | |||||
| Power supply |
Battery: 14.8 V nominal, approx. 100 minutes operating time AC power: 100 V to 240 V, 50/60 Hz (with supplied AC adapter) |
|||||
| Recording media | SDHC card and USB flash memory (Still image recording only) | |||||
| Still image recording | Resolution | H768 x V576 (Pixel) | H1024 x V768 (Pixel) | |||
| Recording format | Compressed JPEG format | |||||
| Video recording | Resolution | H768 x V576 (Pixel) | H1024 x V768 (Pixel) | |||
| Recording format | MPEG-4 AVC (H.264) format, Windows Media Player compatible | |||||
|
Stereo measurement |
Distance | Distance between two points | ||||
| Point-to-line | Perpendicular distance between a point and a user-defined line | |||||
| Depth | Orthogonal depth/height distance between a point and a user-defined plane | |||||
| Area/Lines | Multiple point circumference and area measurement | |||||
| 3D Modeling | Live cross section, X/Y/Z-axis rotation, 2x Color mapping mode | |||||
| Scalar measurement | Distance between two points based on a known measurement in the same plane | |||||
OPTICAL ADAPTOR VARIATION
4.0 mm Optical Adaptors
|
|
|
AT80D/FF-IV94N | AT120D/NF-IV94N | AT120D/FF-IV94N | AT100S/NF-IV94N | AT100S/FF-IV94N | AT70D/70D-IV94N | AT50S/50S-IV94N |
| Optical system | Field of view | 80° | 120° | 120° | 100° | 100° | 70°/70° | 50°/50° |
| Direction of view | Forward | Forward | Forward | Side | Side | Forward | Side | |
| Depth of field*1 | 35 to ∞ mm | 2 to 200 mm | 17 to ∞ mm | 2 to 15 mm | 8 to ∞ mm | 5 to 200 mm | 3 to 150 mm | |
| Distal end | Outer diameter*2 | 4.0 mm | 4.0 mm | 4.0 mm | 4.0 mm | 4.0 mm | 4.0 mm | 4.0 mm |
| Distal end*3 | 20.1 mm | 20.2 mm | 20.1 mm | 22.9 mm | 22.9 mm | 22.3 mm | 26.7 mm |
6.0 mm Optical Adaptors
|
|
|
AT50D/FF-IV96N | AT80D/FF-IV96N | AT120D/NF-IV96N | AT120D/FF-IV96N | AT120S/NF-IV96N | AT120S/FF-IV96N | AT90D/90D-IV96N | AT70S/70S-IV96N |
| Optical system | Field of view | 50° | 80° | 120° | 120° | 120° | 120° | 90°/90° | 70°/70° |
| Direction of view | Forward | Forward | Forward | Forward | Side | Side | Forward | Side | |
| Depth of field*1 | 50 to ∞ mm | 20 to ∞ mm | 7 to 300 mm | 19 to ∞ mm | 4 to 150 mm | 20 to ∞ mm | 5 to 250 mm | 4 to 250 mm | |
| Distal end | Outer diameter*2 | 6.0 mm | 6.0 mm | 6.0 mm | 6.0 mm | 6.0 mm | 6.0 mm | 6.0 mm | 6.0 mm |
| Distal end*3 | 21.3 mm | 21.3 mm | 21.4 mm | 21.4 mm | 26.6 mm | 26.6 mm | 25 mm | 31.2 mm |
*1. Indicates the viewing distance with optimal focus.
*2. The adaptor can be inserted into a ø4.0 mm and ø6.0 mm hole when it is mounted on the scope.
*3. Indicates the length of the rigid portion at the scope’s distal end when mounted.
OPERATING ENVIRONMENT
| Operating temperature | Insertion tube |
In air : -25 to 100 °C (-13 to 212 °F) In water : 10 to 30 °C (50 to 86 °F) |
| Other parts |
In air : -21 to 49 °C (-21 to 120 °F) (with battery) In air : 0 to 40 °C (32 to 104 °F) (with AC power adapter) |
|
| Relative humidity | All parts | 15 to 90 % |
| Liquid resistance | All parts | Operable when exposed to machine oil, light oil or 5 % saline solution |
| Waterproofing | Insertion tube |
Operable under water with viewing tip adaptor attached Not operable underwater with stereo measurement tip adaptors IV94 series: Up to an equivalent to 5 m (16.4 ft.) in depth IV96 series: Up to an equivalent to 7.5 m (24.6 ft.) in depth |
| Other parts | Operable in blowing rain conditions (battery compartment must be closed). Not operable under water |
MIL-STD COMPLIANCE
|
The operating environment performance is confirmed by the following MIL-STD-810F/G and MIL-STD-461F. No warranty is given as to damage-free under any conditions. Please ask Olympus sales representative for details. |
|
| Vibration | MIL-STD-810G, Method 514.6, Procedure I (General vibration test) |
| Shock | MIL-STD-810G, Method 516.6, Procedure IV (Transit drop test) |
| Water Resistance | MIL-STD-810G,Method 506.5, Procedure II (Rain and Blowing rain test) |
| Humidity | MIL-STD-810G, Method 507.5 |
| Salt Fog | MIL-STD-810G, Method 509.5 |
| Sand and Dust | MIL-STD-810G, Method 510.5, Procedure I (Blowing dust test) |
| Icing/Freezing Rain | MIL-STD-810G, Method 521.3 |
| Electromagnetic Interference (EMI) | MIL-STD-461F Above decks |
| Explosive Atmosphere | MIL-STD-810G, Method 511.5 (Operation in an explosive atmosphere test) |
DIMENSIONS
